Vina Tech(Super Capacitor)
VINATech, a Hy-Cap® brand, develops and manufactures eco-friendly supercapacitors surpassing global standards of UL, ISO/TS, and RoHS.
Hy-Cap is an energy storage device that stores instantly a large volume of electric energy and supplies instantly or continuously higher current, by the mechanism of absorbing and de-absorbing electric charge. Hy-Cap’s are made of activated carbons ,processed in an eco-friendly method, which features higher power, density and longer life.
VINATech has been mass-producing the market leading 3.0V EDLC family since 2010 featuring 23% higher energy density than the traditional 2.7V EDLC, VINATech is also the only manufacturer of a hybrid capacitor which uses PC electrolytes. VINATech leads the world, in the production capacity for manufacturing radial supercapacitors of 1F to 1000F class.
Hy-Cap Solutions
Hy-Cap products offer a wide range of options to meet a wide range of applications, varying in voltage, capacitance, terminal type and performance.
| Rated voltage | Hy-Cap models | Description |
|---|---|---|
| 2.3V | Hy-Cap Hybrid | Higher energy density |
| 2.5V, 2.7V, 3.0V | Hy-Cap EDLC | Higher power |
| Terminal type | Hy-Cap models | Description |
|---|---|---|
| Lead type | Hy-Cap lead terminal type | Hybrid or
|
| Snap-in type | Hy-Cap snap-in terminal type | Hybrid or EDLC |
| Axial type | Hy-Cap axial terminal type | EDLC |
| Type of application | Hy-Cap models | Description |
|---|---|---|
| Hy-Cap single cell | Hy-Cap single cell | Hybrid or EDLC |
| 2-serial module | Hy-Cap lead terminal type module | 2-serial sleeve type module 2-serial epoxy-molded type module |
| Customized module | Hy-Cap customized module |
PCB assembly type module Molded-case type module Metal-case type module |
**Customized modules are available by optimizing the capacitance, voltage, current, and size, based on the customer's requests and application area.
Details of Hy-Cap certifications
| Certification | Certification No. | Description |
|---|---|---|
| UL | MH48256 | Certified for US Safety Standards |
| ISO/TS 16949 | 0240429 TSS-0237 | Standards for quality systems of all enterprises within the supply channel of auto industry |
| ISO-14001 | EMS-0757 | International standards for environmental management systems applied to all industrial sectors |
Hy-Cap application areas
Hy-Cap products can be used in a growing number of applications. You can also zoom in the photo by clicking on it.
Smart meters / Network equipment
- Wide operating temperature range: -40 ℃ ~ +85℃
- permanent and no maintenance service required
Automotive after-market products
- For navigation systems or black box memory backup
- Compensate peak power for car audio woofers
UPS / DVR
- Responds to momentary blackouts
- Compensates peak power
- UPS: Uninterruptible Power Supply
- DVR: Dynamic Voltage Restorer
Solar street lamps
- A solar energy storage device
- Wide operating temperature range: -40 ℃ ~ +85℃
- Semi permanent and no maintenance service required
Emergency lamps
- Semi permanent and no maintenance service required
- Excellent stability in an emergency
Wind turbine
- Compensates peak power for pitch control
- Semi permanent and no maintenance service required
Regenerative Energy storage device
- Hybrid electric cars, suitable for an elevators or railway vehicles
- Reduce energy cost and CO2 emissions
Other applications
- Motor running geared toy
- Open and close actuator valves
- Solid State Drives
